Overview

All NFT items in Asylum ecosystem extends pallet_uniques and RMRK standards and inherits tranferability and extensibility. But we want also to bring gaming semantics and interoperability to items, that's why we introduced such abstractions as Blueprint and Interpretation.

Metaverse objects entities flow diagram​

  • Blueprint: The extension of the classic NFT Collection. The Blueprint has a set of supported Interpretations, and all items minted from this Blueprint support these Interpretations as well.
  • Interpretation: The description of the media resource, which is used to interpret the Blueprint in different contexts. To describe such context, Interpretation must be associated with the unique set of Tags. This set of Tags defines the format of Interpretation's metadata.
  • Tag: The Tag is used to give an Interpretation a special semantic, allowing Client to query specific Interpretation according to the context of usage. Tag can describe a list of fields, which forms Interpretaion's metadata.
  • Item: The NFT minted from a particular Blueprint. Item has the same Interpretation list, specified by Blueprint at the time of its minting, but can differ in the future with upgrading the Blueprint. The owner of Item might reject upgrading this Item according to the latest updates of Blueprint.

Blueprint metadata standard​

Blueprint metadata currently contains only the description field and has the following structure:

{
  "name": {
    "type": "string",
    "description": "The name of the interpretation"
  },
  "description": {
    "type": "string",
    "description": "Description of the blueprint as a whole. Markdown is supported."
  }
}

You can find an example of configuring the metadata in the Asylum Node testing guide in the Blueprint section.

Blueprint metadata does not have any additional fields as all the info is stored in the Interpretations and its metadata.

Tag metadata standard​

Every Interpretation in the IMP ecosystem is associated with a specific set of Tags. Consider Tags as a verbal description of Interpretation. Tags can carry interpretation metadata fields with predefined or configurable values, or even without any metadata, bringing specific semantics to the Interpretation (like the pixeled tag).

Besides the common Tag fields like id and description that are used to provide the understanding of the Tag semantics, Tag metadata also has a complex field - metadataExtensions.

metadataExtensions is the object that describes the way how the concrete Tag affects the metadata of Interpretation.

For example png tag can bring the required format field to the metadata with the default value png.

The whole structure of tag metadata:

{
  "id": "string",
  "description": "string",
  "metadataExtensions": {
      "fields": [
        {
          "name": "string",
          "type": "string",
          "default": "any",
          "description": "string"
        }
      ]
  }
}

You can find an example of configuring the metadata in the Asylum Node testing guide in the Tags section.

Interpretation metadata standard​

Interpretation metadata contains only the description field but can be extended by Tags (see examples in the next section).

The structure of interpretation metadata:

{
  "description": "string",
  "tag-metadata-field-name": "tag-metadata-field-name"
}

Examples of metadataExtensions usage​

Let's consider a few examples of metadataExtensions usage.

  1. Fist one is the pixeled tag, which is used to define pictures in pixeled style and can bring fields like pixel-size or smoothed.

Metadata of the pixeled tag:

{
  "id": "pixeled",
  "description": "in pixeled style",
  "metadataExtensions": {
      "fileds": [
        {
          "name": "pixel-size",
          "type": "number",
          "default": "",
          "description": "Size of pixeles"
        },
        {
          "name": "smoothed",
          "type": "boolean",
          "default": false,
          "description": "Is image smoothed"
        }
      ]
  }
}

Metadata of interpretations with pixeled tag:

{
  "description": "interpretation description",
  "pixel-size": 128,
  "smoothed": false,
}
  1. Another example is the animation-sprite-atlas tag, which is used to define an atlas for 2d animation and will bring required fields like tile-size-h, tile-size-w, tiles-count, and padding.

Metadata of the animation-sprite-atlas tag:

{
  "id": "animation-sprite-atlas",
  "description": "sprite atlas used for the 2d animation",
  "metadataExtensions": {
      "fileds": [
        {
          "name": "tile-size-h",
          "type": "number",
          "default": "",
          "description": "Height of every tile in pixels"
        },
        {
          "name": "tile-size-w",
          "type": "number",
          "default": "",
          "description": "Width of every tile in pixels"
        },,
        {
          "name": "padding",
          "type": "number",
          "default": "",
          "description": "Padding between tiles in pixels"
        }
        {
          "name": "tiles-count",
          "type": "number",
          "default": "",
          "description": "Count of all tiles in the atlas"
        }
      ]
  }
}

Metadata of interpretations with animation-sprite-atlas tag:

{
  "description": "interpretation description",
  "tile-size-h": 64,
  "tile-size-w": 64,
  "tiles-count": 21,
  "padding": 2,
}
